| No. |
ITEM |
SPEC & THECHNICAL DESCRIPTIONS |
| 1. |
Drive Motor |
Permanent magnet synchronous motor tDrive-MD2021 (180/280kW) |
| 2. |
Power Battries |
Lithium iron phosphate 350.07kWh/422.9kWh |
| 3. |
Controller |
Integrated control system tDriver-TP5 |
| 4. |
Vehicle charging port |
Single port 200A CCS |
| 5. |
Front/Rear Axle |
ZF low floor Axle Front Axle: 8500KG, Rear Axle: 13000KG |
| 6. |
Steering Position |
LHD |
| 7. |
Steering |
Integrated power steering system, electric oil pump BOSCH 8098 |
| 8. |
Thermal management system |
ATS heat management system, water-cooled radiator and electric fan |
| 9. |
Air compressor |
Oil free piston electric air compressor |
| 10. |
Suspension |
ZF air suspension with 6 air bag, WABCO ECAS |
| 11. |
Tyre |
Tubeless radial 275/70R22.5*6 |
| 12. |
Brake System |
Dual Circuit Air Brake, Front Disc, Rear Disc, Wabco EBS, |
| 13. |
Centralization Lubrication(Optional) |
Automatic Centralization Lubrication |
| 14. |
Frame |
Monocoque Body |
| 15. |
Entry |
Low floor |
| 16. |
F/R Wind Shield |
Front Laminated Wind Screen, Rear Toughened Glass |
| 17. |
Side Window |
Toughened Glass(Single Glass) |
| 18. |
Shine Shield |
Driver Front/ Side Shields |
| 19. |
Passenger Seats |
Standard |
| 20. |
Driver Seats |
ISRI NTS6860/875 |
| 21. |
Passenger Capacity |
32 passenger seats, 1 driver seat, 1 wheel chair,2 folding seats, 60 standee |
| 22. |
Passenger Door |
2-3 pneumatic inward-double doors, clear width 1200mm (OP: Sliding door) |
| 23. |
Driving Cab |
Independent cab fordriver |
| 24. |
Wheel Chair Ramp |
Manual ramp in the middlle door, with lock and warning device |
| 25. |
Instrument |
Actia Combination Instrument with CAN bus |
| 26. |
A/C & Heating System |
VALEO 28000 Kcal A/ C, with Heating |
| 27. |
Safety Skylight |
One Manual Windows on the Roof |
| 28. |
Passenger Ceiling Light |
LED Through Lamp |
| 29. |
Step Lamp |
Boarding and Taking-off Step Lights (three) |
| 30. |
Batteries |
Lead-acid Maintenance-free 120Ah*2 |
| 31. |
On Board Monitor |
7-Inch Color LCD Screen, with Automatic Switching Function of
Reversing Monitoring and Vehicle Middle Door Monitoring |
| 32. |
Electric Horn |
1 Treble + 1 Bass |
| 33. |
Interior Speakers |
Power 30W, Impedance 8 Ω, 6 pcs |
| 34. |
Getting-Off Bell |
Wireless Bell, 1 Button, 1 Receiver, 1 Display |
| 35. |
Display Board |
Front Rear Side LED electric display board(OP: HANNOVER) |
| 36. |
PDC Parking Distance Control |
With PDC Parking Distance Control |
| 37. |
Reversing Alarm |
Voice, Voltage 24 V, Sound Pressure 75 ~ 100 dB, 1pcs |
| 38. |
Painting |
Ordinary Painting; Customized |
| 39. |
Driving Recorder |
VDO DTCO 4.0 |
| 40. |
Others |
Wipers: DOGA NATO SOCKET |
